EXTS - Intra 27kW/48V
27kW Floor-Mounted Indoor Power System for Telecom Rooms
Reliable DC Power for Indoor Equipment Rooms
EXTS - Intra 27kW/48V is Exicom's floor-mounted, IP20 indoor power system for telecom sites that have outgrown a rack-mounted subrack but don't need an outdoor cabinet. Its 3kW EXTR Quantum 3048 rectifier modules deliver up to 96.5% efficiency with VRLA and Li-Ion battery support, managed through the M2000 Controller alongside swappable rectifiers and built-in battery management. ECO Mode energy savings and standard remote monitoring via web browser, Modbus, and SNMP, plus advanced AC and DC energy metering, give indoor equipment rooms the same operational visibility as Exicom's compact subracks, at a scale suited to larger sites.
Product Features
- System Contain – M2000 Controller + Rectifier + Battery Distribution + Load Distribution
- Swappable Rectifiers & Controller
- Comprehensive battery management & built-in support for Li-ion battery charge
- ECO Mode function for rectifier enabling significant energy savings.
- Remote Access – Monitoring through the web browser, Modbus & SNMP as a standard feature
- High Efficiency up to 96.5%
- Advanced AC and DC energy metering options
Tech specs
- AC Input: 3Phase, 90-300Vac (Nominal Voltage: 230Vac)
- Max Output Power: 27kW
- Rectifier Module: 3KW (EXTR Quantum 3048)
- Output Voltage: 54Vdc (42-58Vdc)
- Battery Compatibility: VRLA/Li Ion
- Cooling: Natural
- Mounting: Floor mount
- IP 20 Indoor solution
- Dimensions : 530mm (H) x 486mm (W) x 428mm(D)
