EXTB 10048
48V LiFePO4 Telecom Battery for Space-Saving Backup (100Ah, 3U)
Space-Saving Lithium Battery Backup for Compact Telecom Sites
The EXTB 10048 packs 100Ah of LiFePO4 capacity and 4.8kWh of usable energy into a compact 3U chassis, giving space-constrained telecom sites a lighter, smaller backup option without giving up performance. Its integrated smart BMS manages current-limiting, over and under-voltage, and over-temperature protection, while dual RS485 and RS232 ports deliver remote visibility through SOC, alarm, and run status indicators. Rated for over 3000 cycles at 80% DOD and 90%+ charge-discharge efficiency, it operates across a wide temperature range from -20°C to 60°C. Capacity extends through parallel connection as your site grows.
Product Features
- LiFePO4 (LFP) chemistry for high energy density
- Extendable capacity through parallel connection
- High safety ensured by integrated smart BMS
- Wide working temperature range (charge 0°C–60°C, discharge -20°C–60°C)
- Perfectly fits telecom standard 19-inch cabinets in a compact 3U footprint
- Long cycle life
- High discharge/charge efficiency of more than 90%
- RS485 x2 and RS232 communication ports with SOC/ALM/RUN status indicators, reset key and LED interface
Tech specs
- Nominal Voltage: 48V
- Nominal Capacity: 100Ah / 4.8kWh
- Operating Voltage: 40.5–56V
- Max Charge/Discharge Current: 100A @ 25°C
- Operating Temperature: -20°C to 60°C
- Weight: Approx 38 kg
- Dimensions: 445 x 450 x 133.5mm, 3U
- Communication: RS485 x2, RS232 x1
